Marwi Headset - Semi integrated (ZS44) 1-1/8"

MARWI HEADSET - SEMI INTEGRATED

The Marwi headset is a semi-integrated (ZS) type, specifically designed for frames equipped with a 1-1/8" head tube. Made from aluminum, this headset offers easy installation and ensures smooth and responsive handling.

Semi-integrated headset: Zero Stack (ZS)

The semi-integrated headset (or ZS, Zero Stack) uses bearings placed in cups that are integrated into the head tube. This is why the head tubes have a larger diameter, which results in improved rigidity. There is also an aesthetic advantage compared to a headset with external cups.

SPECIFICATIONS

• Material : Aluminum / Steel (Bearings)
• Headset type : Semi-integrated (ZS)
• SHIS code (top) : ZS44/28.6
• SHIS code (bottom) : ZS44/30
• Bearing size : 30.2x41x6.5 - 36°x45°
• Fork compatibility : 1-1/8"
• Weight : 109g (with compression star nut)

KIT CONTENT

• 2x Cups
• 2x Bearings
• 1x Fork cone
• 1x Compression ring
• 1x Cover
• 1x Upper cap
• 1x Compression star nut
