SD Ace Rear Hub ISO6 - 15mm

SD COMPONENTS ACE ISO 6 15MM Rear Hub

This rear hub is specially designed for BMX Race. It features sealed bearings and an ultra-lightweight aluminum body. It offers almost instant engagement with its 180 points of contact and 6 pawls/springs. Thanks to its ultra-strong ISO 6 system, the ACE ensures excellent disc stability even during powerful braking. The hub body is designed to accommodate a 15mm thru-axle. The SD ACE hub is a formidable asset for competition and performance-oriented riders.

NOTE : The hub comes with a lock ring and two spacers (2mm/5mm) to adjust the chainline. It does not include a 15mm axle.

DETAILS :

• Hub Body Material : Aluminum
• Hub Spacing : 110mm
• Cog Attachment : Standard Shimano
• Bearing Type : 2x SC03T02 LU - 100% sealed (Hub Body) / 2x 18307 LU - 100% sealed (Driver)
• Cassette Type : 6 pawls / 6 springs
• Number of Engagement Points : 180
• Color: Black
• 15mm Thru-Axle (not included with the hub)
• Comes with 2 spacers: 2.5mm; 5mm
• Disc Mounting System: ISO 6
• Bearing Reference: Not provided
• 100% Sealed Bearings
• Number of Spoke Holes: 36H
• Weight: 341g
